Baja Designs Fog Pocket Light Kit Squadron / Sport Series SAE Pattern Clear Lens Upfitter Wiring

This kit is perfect if you are looking to spice up your Ford F-150 ('21-22) with a premium lighting kit. This kit specifically utilizes a set of Squadron SAE and a set of Squadron Sport in driving combo lens pattern. This kit also includes powder-coated fog pocket brackets, stainless-steel hardware as well as our custom harness.One pair of Squadrons will be operable off your OEM fog light switch, and both pairs of Squadrons can be turned on with our provided toggle switch harness. The next generation Squadron SAE is the perfect road-legal auxiliary fog light on the market today.Engineered with all-new aspheric projector optics and with our advanced LED technology provides a performance increase in luminous flux of 56 Percent over our previous generation SAE model.Keeping you safe on the road or trails, the Squadron SAE will illuminate Zone 1 with a controlled, sharp cutoff from the combination of the new LED technology and highly efficient aspheric projector optics.Designed to meet the current SAE J583 fog lamp requirements, the Squadron SAE is fully compliant with on-road regulations. This innovative approach allows for a highly controlled light pattern with a sharp cutoff, making them an ideal choice for driving through dust, fog, and inclement weather. Backed by our limited lifetime warranty and 30-day satisfaction guarantee, giving you the ultimate in-purchase protection.Note: This kit comes with everything you need to install and is designed to be used on the F-150 without Daytime Running Lights (DRL). USPTO Reg No. 5,766,659Specifications (Per SAE):Dimensions:3.07 Inch x 2.77 Inch x 3.07 InchWeight:12 ouncesLED Life Expectancy:49,930 HoursFront Lens:Hard Coated PolycarbonateHousing:Powder Coated Cast AluminumBezel:Billet Machined AluminumHardware and Bracket Material:Stainless SteelExceeds MIL-STD810G (Mil-Spec Testing)Built-In Overvoltage ProtectionIP69K (Waterproof, Submersible to 9ft)IK10 Compliant (Mechanical Impact Testing)Specifications (Squadron Sport):Lumens:3,150 Utilizing 4 LEDsWattage/Amps:26W / 2ADimensions:3.07 Inch x 2.77 Inch x 3.07 InchWeight:12 ouncesLED Life Expectancy:49,930 HoursFront Lens:Hard Coated PolycarbonateHousing:Powder Coated Cast AluminumBezel:Billet Machined AluminumHardware and Bracket Material:Stainless SteelExceeds MIL-STD810G (Mil-Spec Testing)Built-In Overvoltage ProtectionIP69K (Waterproof, Submersible to 9ft)IK10 Compliant (Mechanical Impact Testing)Baja Designs Features:Satisfactions Guarantee:30 Day Money Back GuaranteeLimited Lifetime Warranty:Complete Purchase ProtectionuService:Replaceable Lenses And OpticsClearView:All The Light, Right Where You Need It.MoistureBlock Waterproof, Rain Proof, SubmersibleCopperDrive:Only LED Driven At 100 Percent5000K Daylight:Less Driver Fatigue, Natural ColorApplication:Ford F150 (21 - On)Included:Squadron Sport, Driving/Combo PairSquadron SAE, Clear Wide Cornering Pairx2Fog Pocket Bracketsx2 Wire Adaptersx1 Toggle Switch Harnessx2 55 Inch Splittersx2 small SplittersPatterns:Driving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42 Degree ) and spot (8 Degree ) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)Wide Cornering:BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42 Degree flattened horizontal beam for the ultimate in comfort lighting. (Lighting Zones 1 and 2)

Brand: Baja Designs
Part Number: 447697UP

Fitment:

• Ford F-150 King Ranch 2023
• Ford F-150 Lariat 2023
• Ford F-150 Limited 2023
• Ford F-150 Platinum 2023
• Ford F-150 Police Responder 2023
• Ford F-150 Raptor 2023
• Ford F-150 Raptor R 2023
• Ford F-150 SSV 2023
• Ford F-150 Tremor 2023
• Ford F-150 XL 2023
• Ford F-150 XLT 2023

Note: Image is for reference only, actual product may vary slightly.
