RMStator Generator Stator RMS010-101409

Brand new aftermarket stator

• You must re-install your original connector (see picture).
• Once your connector and is re-installed, our part becomes a Plug-and-play unit, direct fit, and very easy to install.
• Highest grade lamination materials
• Highest grade copper windings, resistant to 200 degrees Celsius.
• Rubber grommet included
• All products shipped are tested

We have even included the opposite connector (main harness side) as we know these are often melted / corroded / defective and a major cause for repetitive electrical issues.

All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.

Technical Data

Dimensions :

Interior diameter : 42 mm
Exterior diameter : 103 mm
Thickness : 16 mm
Length of wires stator to grommet : 43 mm
Length of wires grommet to plug : 220 mm

Other specifications :

Number of wires : 4
Number of plugs : 1
Number of pins : 4

Wire to wire resistance :

Alternator : Black to Black = 0.8 ohms +-20%

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS010-101409

Fitment:

• 1986-1987 Kawasaki Eliminator 600 ZL600A
• 1996-1997 Kawasaki Eliminator 600 ZL600A
• 1985-1997 Kawasaki Ninja 600R ZX600A
• 1985-1986 Kawasaki Ninja ZX6 ZX600D

Note: Image is for reference only, actual product may vary slightly.
