RMStator Stator Ignition For 1996-2004 Honda XR250R RMS010-101542

Brand new aftermarket stator

• Direct replacement to your original unit
• Plug-and-play, direct fit, easy installation
• Highest grade of lamination materials
• Highest grade of copper winding, resistant to 200 degrees Celsius.
• Connector included
• Rubber grommet included
• All products shipped are tested

All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.

Technical Data

Dimensions :

Interior diameter : 35 mm
Exterior diameter : 92.8 mm
Thickness : 8 mm
Length of wires stator to grommet : 85 mm
Length of wires grommet to plug : 500 mm
Length of wires Pickup coil to grommet : 90 mm

Other specifications :

Number of wires : 5
Number of plugs : 4
Number of pins : 5

Wire to wire resistance :

Alternator : Red to Yellow = 1.1 ohms +-20%
Source Coil : Black/Red to Green = 160 ohms +-20%

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS010-101542

Fitment:

• 1996-2004 Honda XR250R

Note: Image is for reference only, actual product may vary slightly.
