RMStator Generator Stator RMS010-102166

Brand new aftermarket ganerator stator

• Direct replacement to your original unit
• Plug-and-play, direct fit, easy installation
• Highest grade lamination materials
• Highest grade copper windings, resistant to 200 degrees Celsius.
• Pick up pulsar coil included
• Connector included
• Rubber grommet included
• All products shipped are tested

We have even included the opposite connector (main harness side) as we know these are often melted / corroded / defective and a major cause for repetitive electrical issues.

All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.

Technical Data

Dimensions :

Interior diameter : 38 mm
Exterior diameter : 108 mm
Thickness : 19 mm
Length of wires stator to grommet : 120 mm
Length of wires grommet to plug : 550 mm
Length of pickup coil's wire to grommet : 59 mm

Other specifications :

Number of wires : 5
Number of plugs : 2
Number of pins : 5

Wire to wire resistance :

Alternator : Black to Black = 0.5 ohms +-20%
Pickup : Green to White = 194 ohms +-20%

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS010-102166

Fitment:

• 2003-2009 Suzuki SV650
• 2003-2009 Suzuki SV650S
• 2004-2007 Suzuki Vstrom 650 DL650

Note: Image is for reference only, actual product may vary slightly.
