RMStator Stator RMS010-104672
Customer Ratings
RMStator Stator RMS010-104672
RMStator Stator RMS010-104672
Brand new aftermarket Stator
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Connectors included
- Rubber grommet included
- All products shipped are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Technical Data
Dimensions :
Length of wires stator to grommet : 90 mm
Length of wires grommet to plug : 165 mm
Length of pickup coil's wire to grommet : 220 mm
Other specifications :
Number of wires : 11
Number of plugs : 1
Number of pins : 11
Number of poles : 2
Wire to wire resistance :
Alternator : Between each Green = 0.4 ohms +-20%
Pickup : White / Black to White / Red = 500 ohms +-20%
Source : Brown to Blue = 350 ohms +-20%
RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.
We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.
THE POWER IN POWERSPORTS
Brand: RMStator
Part Number: RMS010-104672
Fitment:
- 1996-1997 Yamaha Wave Blaster II 760
- 1996 Yamaha WaveRaider 760 RA760
- 1997-2000 Yamaha WaveRunner GP760
- 1998-1999 Yamaha WaveRunner XL760
- 1997 Yamaha WaveVenture 760 WVT760
Note: Image is for reference only, actual product may vary slightly.
