RMStator High Output Stator RMS010-107562
RMStator High Output Stator RMS010-107562
Brand new aftermarket Stator
- Direct replacement to your original unit
- 80 Watt DC
- This stator increase power output significantly
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Connectors included
- Rubber grommet included
- All products shipped are tested
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Technical Data
Dimensions:
Interior diameter: 32 mm
Exterior diameter: 76 mm
Thickness: 17 mm
Length of wires stator to grommet: 125 mm
Length of wires grommet to plug: 510 mm
Length of pickup coil's wire to grommet: 100 mm
Other specifications:
Number of wires: 4
Number of plugs: 1
Number of pins: 4
Number of poles: 12
Wire to wire resistance:
Alternator: Yellow to Yellow = 0.4 ohms +-20%
Alternator: Yellow to ground = O.L
Pickup: Green to Red = 133 ohms +-20%
RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.
We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.
THE POWER IN POWERSPORTS
Brand: RMStator
Part Number: RMS010-107562
Fitment:
- 2021 GAS GAS EX250
- 2021 GAS GAS EX350 F
- 2021 GAS GAS EX450 F
- 2021 GAS GAS MC250
- 2021 GAS GAS MC450 F
- 2016-2021 Husqvarna FC250
- 2016-2021 Husqvarna FC350
- 2016-2021 Husqvarna FC450
- 2017-2020 Husqvarna FS450
- 2017-2020 Husqvarna FX350
- 2017-2021 Husqvarna FX450
- 2011-2012 KTM 250 SXF
- 2015-2022 KTM 250 SXF
- 2017-2021 KTM 250 XC-F
- 2016 KTM 250 XCF-W
- 2016-2022 KTM 350 SXF
- 2017 KTM 350 XC-F
- 2019-2022 KTM 350 XC-F
- 2016 KTM 350 XCF-W
- 2021 KTM 450 SMR
- 2015-2022 KTM 450 SXF
- 2017-2021 KTM 450 XC-F
Note: Image is for reference only, actual product may vary slightly.
