RMStator High Output Stator RMS010-107564
RMStator High Output Stator RMS010-107564
Brand new aftermarket Stator
- Direct replacement to your original unit
- 70 Watt DC
- This stator increase power output significantly
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Connectors included
- Rubber grommet included
- All products shipped are tested
20% MORE OUTPUT OVER STOCK, WORKS WITH ALL OTHER OEM COMPONENTS.
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Technical Data
Dimensions:
Interior diameter: 29 mm
Exterior diameter: 77 mm
Thickness: 21 mm
Length of wires stator to grommet: 120 mm
Length of wires grommet to plug: 520 mm
Length of pickup coil's wire to grommet: 90 mm
Other specifications:
Number of wires: 4
Number of plugs: 1
Number of pins: 4
Number of poles: 12
Wire to wire resistance:
Alternator: Yellow to Yellow = 0.4 ohms +-20%
Alternator: Yellow to ground = O.L
Pickup: Red to Green = 130 ohms +-20%
RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.
We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.
THE POWER IN POWERSPORTS
Brand: RMStator
Part Number: RMS010-107564
Fitment:
- 2014-2015 Husqvarna FC250
- 2014-2015 Husqvarna FC350
- 2011-2015 KTM 250 SXF
- 2011-2015 KTM 250 XC-F
- 2011-2015 KTM 350 SXF
- 2012-2015 KTM 350 XC-F
Note: Image is for reference only, actual product may vary slightly.
