RMStator Capacitor Coil RMS060-103888
Customer Ratings
RMStator Capacitor Coil RMS060-103888
RMStator Capacitor Coil RMS060-103888
Brand New Aftermarket External Ignition Coil
- Ignition Coil For P Model Engines
- Replaces Onan part number(s): 541-0522, HE166-0761, c32296, 714000, NN10245, 98-1705
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
Serial number and other restrictions apply to this product:
- 316 - Must have the P218G engine Serial numbers 420,001 to 999,000 & Serial numbers 10,001 to 120,000
- 317 - Must have the replacement Onan P218G engine in the tractor No serial number range is affected, you must check your engine model. This part will not fit Kohler engines.
- 318 - Must have the P218G engine Serial numbers 420,001 to 999,000 & Serial numbers 10,001 to 120,000
- 420 - Must have the P220G engine Serial numbers 420,001 and above
- F910 - Serial numbers between 420001-750000 and 010001-100000
- F930 - Serial numbers between 420001-750000
- Not for use on points systems.
- All products shipped are tested
*All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.
Technical Data
Dimensions:
Width: 51 mm
Length: 102 mm
Height: 61 mm
Fixation holes center to center: 28.5 mm
Primary Resistance - 4.25 ohms
Primary Inductance - 9.48 mH
Secondary Resistance - 37.85 K ohms
Secondary Inductance - 59.96 H
RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.
We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.
THE POWER IN POWERSPORTS
Brand: RMStator
Part Number: RMS060-103888
Fitment:
- All John Deere 316 - P218G Engine
- All John Deere 317 - Onan P218G Engine
- All John Deere 318 - P218G Engine
- All John Deere 420 - P220G Engine
- All John Deere F910
- All John Deere F930
- All John Deere P224G Engine
Note: Image is for reference only, actual product may vary slightly.
