RMStator High Output Stator And Flywheel RMS900-107872

Brand new Kit Magneto Flywheel + Stator

• Direct replacement to your original unit
• Plug-and-play, direct fit, easy installation
• All shipped products are tested
Brand new stator
• Highest grade of lamination materials
• Highest grade of copper winding, resistant to 200 degrees Celsius
• Connector, pick up pulsar coil, rubber grommet included

Magneto Flywheel Rotor

Brand new Magneto Flywheel Rotor

• All products shipped are tested

All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part

Technical Data

Stator

Dimensions:
Interior diameter: 27 mm
Exterior diameter: 79 mm
Thickness: 13 mm
Length of wires stator to grommet: 80 mm
Length of wires grommet to plug: 450 mm

Other specifications:

Number of wires: 5
Number of plugs: 5
Number of pins: 5
Number of poles: 2
Wire to wire resistance:
Alternator: Yellow/Red to Black = 0.6 ohms +-20%
Black Wire is Grounded
Pickup: White/Red to Black = 24 ohms +-20%
Source: Black/Red to Green/White = 230 ohms +-20%

Magneto Flywheel Rotor

Dimensions:
Exterior Diameter: 118 mm
Interior Diameter: 84.5 mm
Interior Diameter Center Housing: 19 mm
Exterior Diameter Center Housing: 26 mm
Thickness (exterior): 45 mm
Thickness (interior): 40 mm

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS900-107872

Fitment:

• 1988-2006 Yamaha Blaster 200 YFS200

Note: Image is for reference only, actual product may vary slightly.
