Dakota Digital Odyssey Chrome 2-1/16" Quad Air Pressure Gauge With Teal Display
Customer Ratings
Dakota Digital Odyssey Chrome 2-1/16" Quad Air Pressure Gauge With Teal Display
Dakota Digital Odyssey Chrome 2-1/16" Quad Air Pressure Gauge With Teal Display
NOTES:
The ODYR-19-7 Quad Air Pressure gauge can monitor and simultaneously display the front and rear pressure on front/ rear or four wheel independent air ride systems to display each air bag for proper pressure. Selectable second screen displays tank pressure.Dakota Digital Odyssey Series II instruments offer a high brightness, non-glare vacuum fluorescent display for excellent daytime visibility and a lifetime of trouble free use. Odyssey Series II instruments are fully backed by a Limited 24-month Warranty against manufacturer defects and provide the accuracy and performance you've come to expect from Dakota Digital
Range: 0- 300 psi.
A single sensor will be required for each pressure reading. For example, a full independent (front/back/side to side) air system would require 4 sensors (1 for each airbag). A fifth sensor (SEN-03-9) can be added to monitor the air tank pressure if desired.
Resolution: 1 psiSeparate control box for easy installation.User adjustable high and low warning points can trigger a external light or buzzer. (not included)Night dimming.
Choice of either Black or Chrome bezel.Machined aluminum housing.
Note: Required BIM-19-2 Included
Range: 0- 300 psi.
A single sensor will be required for each pressure reading. For example, a full independent (front/back/side to side) air system would require 4 sensors (1 for each airbag). A fifth sensor (SEN-03-9) can be added to monitor the air tank pressure if desired.
Resolution: 1 psiSeparate control box for easy installation.User adjustable high and low warning points can trigger a external light or buzzer. (not included)Night dimming.
Choice of either Black or Chrome bezel.Machined aluminum housing.
Note: Required BIM-19-2 Included
Brand: Dakota Digital
Part Number: ODYR-19-7-C
Note: Image is for reference only, actual product may vary slightly.
Dakota Digital Odyssey Chrome 2-1/16" Quad Air Pressure Gauge With Teal Display
NOTES:
The ODYR-19-7 Quad Air Pressure gauge can monitor and simultaneously display the front and rear pressure on front/ rear or four wheel independent air ride systems to display each air bag for proper pressure. Selectable second screen displays tank pressure.Dakota Digital Odyssey Series II instruments offer a high brightness, non-glare vacuum fluorescent display for excellent daytime visibility and a lifetime of trouble free use. Odyssey Series II instruments are fully backed by a Limited 24-month Warranty against manufacturer defects and provide the accuracy and performance you've come to expect from Dakota Digital
Range: 0- 300 psi.
A single sensor will be required for each pressure reading. For example, a full independent (front/back/side to side) air system would require 4 sensors (1 for each airbag). A fifth sensor (SEN-03-9) can be added to monitor the air tank pressure if desired.
Resolution: 1 psiSeparate control box for easy installation.User adjustable high and low warning points can trigger a external light or buzzer. (not included)Night dimming.
Choice of either Black or Chrome bezel.Machined aluminum housing.
Note: Required BIM-19-2 Included
Range: 0- 300 psi.
A single sensor will be required for each pressure reading. For example, a full independent (front/back/side to side) air system would require 4 sensors (1 for each airbag). A fifth sensor (SEN-03-9) can be added to monitor the air tank pressure if desired.
Resolution: 1 psiSeparate control box for easy installation.User adjustable high and low warning points can trigger a external light or buzzer. (not included)Night dimming.
Choice of either Black or Chrome bezel.Machined aluminum housing.
Note: Required BIM-19-2 Included
Brand: Dakota Digital
Part Number: ODYR-19-7-C
Note: Image is for reference only, actual product may vary slightly.
