RMStator Stator CDI Box Coil Kit RMS900-006019

Brand New aftermarket High Output Stator + Voltage Regulator Rectifier + PeakRPM CDI Box + External Ignition Coil Kit

• Direct replacement to your original unit
• All shipped products are tested

*All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.

• Plug-and-play, direct fit, easy installation
• Highest grade of lamination materials
• Highest grade of copper winding, resistant to 200 degrees Celsius
• Pick up pulsar coil included
• Connector included
• Rubber grommet included

We have even included the opposite connector (main harness side) as we know these are often melted/corroded/defective and a major cause for repetitive electrical issues.

• Plug-and-play, direct fit, easy installation
• No assembly required
• Higher grade of electric components
• Improved heat sink and charging capabilities
• The quality exceeds the OEM equipment

We have even included the opposite connector (main harness side) as we know these are often melted / corroded / defective and a major cause for repetitive electrical issues.

• Our PeakRPM CDI Box provides the optimal output for your ride
• Higher grade of electronic components
• The Quality exceeds the OEM equipment

Our CDI may use a different wire color code than your original.
All the wires are installed in the correct order; please do not change any of the wiring configurations.
This CDI is designed as a direct plug-in replacement and should be used as such.

• Plug-and-play, direct fit, easy installation
• Highest grade of lamination materials
• Spark plug cap(s) included

Technical Data

High Output Stator Dimensions
Interior diameter : 54 mm
Exterior diameter : 115 mm
Thickness : 14 mm
Length of wires stator to grommet : 150 mm
Length of wires grommet to plug : 500 mm
Length of pickup coil's wire to grommet : 150 mm

Other specifications :

Number of wires : 7
Number of plugs : 2
Number of pins : 7

Wire to wire resistance :

Alternator : White Between Each White = 0.4 ohms +/-20%
Pickup : Blue To Green = 450 ohms +/-20%
Position sensor : Red To White/Blue = 0.4 ohms +/-20%

Voltage Regulator rectifier Dimensions
Width : 89 mm
Length : 91 mm
Height: 27 mm
Fixation holes center to center : 65 mm

Other specifications :
Number of plugs : 1
Number of pins : 6

PeakRPM CDI Box Dimensions
Height: 27 mm
Length: 110 mm
Width: 92 mm
Fixation holes center to center: 120 mm

Other specifications:

Number of plugs: 3
Number of pins: 18

Please note that: The only real way to test your CDI box is to swap it out with another known good unit from the same year/make/model. Because of this; we recommend that you rule everything else out before replacing the CDI box.

External Ignition Coil Dimensions
Width: 50 mm
Length: 48 mm
Height: 35 mm
Wires length: 400 mm
Fixation holes center to center: 55 mm

Other specifications:
Number of plugs: 1
Number of pins: 1
Number of wires: 2
Minimum Charging Voltage: 14.5 V +- 0.5 V
Maximum Charging Current: 50 A / 500 W
Open Circuit Voltage: 15 V
Operation Temperature: -20? to 85?

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS900-006019

Fitment:

• 2002-2008 Yamaha Grizzly 660 YFM660FA 4x4
• 2004-2007 Yamaha Rhino 660 YXR660FA 4x4

Note: Image is for reference only, actual product may vary slightly.
