RMStator Stator Mosfet Kit RMS900-107638

RMStator Stator Mosfet Kit RMS900-107638

Brand new aftermarket Stator + Brand new RMSTATOR Red Machined Aluminum Mosfet Voltage Regulator Rectifier

• Direct replacement to your original unit
• Plug-and-play, direct fit, easy installation
• Connectors included
• Rubber grommet included
• All products shipped are tested

All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.

• Highest grade of lamination materials
• Highest grade of copper winding, resistant to 200 degrees Celsius
• Pick up pulsar coil included
RMSTATOR Red Machined Aluminum Mosfet Voltage Regulator Rectifier
• No assembly required
• Higher grade of electric components
• Improved heat sink and charging capabilities
• The quality exceeds the OEM equipment

We have even included the opposite connector (main harness side) as we know these are often melted / corroded / defective and a major cause of repetitive electrical issues.

All item pictures are accurate, if in doubt, do not hesitate and compare our item to your original part.

Technical Data

Stator

Dimensions:
Interior diameter: 42 mm
Exterior diameter: 115 mm
Thickness: 22 mm
Length of wires stator to grommet: 140 mm
Length of wires grommet to plug: 530 mm & 590 mm
Length of pickup coil's wire to grommet: 155 mm

Other specifications:

Number of wires: 5
Number of plugs: 2
Number of pins: 5
Number of poles: 18
Wire to wire resistance:
Alternator: Black to Black = 0.5 ohms +-20%
Alternator: to ground = O.L
Pickup: Green to Blue = 200 ohms +-20%

Dimensions:
Width: 95 mm
Length: 90 mm
Height: 30 mm
Wires length: 811 mm & 350 mm
Fixation holes center to center: 75 mm

Other specifications:
Number of plugs: 2
Number of pins: 5
Number of wires: 5
Minimum Charging Voltage: 14.5 V +/- 0.5 V
Maximum Charging Current: 50 A / 500 W
Open Circuit Voltage: < 15 V
Operation Temperature: -20&deg to 85&deg

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS900-107638

Fitment:

• 2006-2020 Triumph Daytona 675
• 2008-2017 Triumph Street Triple 675
• 2008-2017 Triumph Street Triple R 675
• 2019-2020 Triumph Street Triple R 675

Note: Image is for reference only, actual product may vary slightly.

OEM Numbers:
107638-R00
