Vance & Hines "Race Shop Components" Beehive Valve Spring kits are designed with the latest advancements in valve spring technology. These High-Performance Beehive Valve Springs are Nano-Peened, polished and 100% inspected through load testing to ensure they exceed stringent quality standards. Offering superior valve stability at high RPM range, they are the premier choice for your performance upgrade, including "drop-in" ready; no machining to heads required. Kits come with all necessary hardware required: springs, retainers, spring bases, keepers and Viton^® valve seals.

• Precision CNC-machined from a stainless one-piece forging for higher strength and durability
• High-grade alloy allowing the valve to withstand high heat and still maintain roundness
• Chromed coating on all stainless valves
• Micropolished stem for smoother finish and less friction resulting in improved performance
• Multiangle back cuts for enhanced flow
• Track tested and proved design on the world's fastest Pro Street and Pro Mod motorcycles
• Retainers made from 4140 chromoly steel, heat-treated and processed to mainain high strength and lightweight design
• Keepers type FM0D7, lock angle 7° triple radius groove, standard install height
• Equipped with chromoly spring bases
• Kits come with premium Viton® seals that are designed for maximum retention of elastic properties
• Stainless Steel
• .600" Max Lift
• Spring Diameter: Large end
• - OD: 1.445"
• - ID: 1.000"
• Spring Diameter: Small End
• -OD: 1.095"
• -ID: 0.650"
• Installed height: 180 lbs. and 1.850"
• Open Load: 400 lbs. and 1.250"
• Spring Rate: 370 lbs.-in.
• Coil Bind (Max): 1.210"

Fitment

• 2005-2017 Harley-Davidson FLD103 Switchback
• 2005-2017 Harley-Davidson FLHP Police
• 2005-2017 Harley-Davidson FLHR Road King
• 2005-2017 Harley-Davidson FLHR103 Road King
• 2005-2017 Harley-Davidson FLHRC Road King Classic
• 2005-2017 Harley-Davidson FLHRCI Road King Classic
• 2005-2017 Harley-Davidson FLHRS Road King Custom
• 2005-2017 Harley-Davidson FLHRSE CVO Road King
• 2005-2017 Harley-Davidson FLHRSE5 ANV CVO Road King 5
• 2005-2017 Harley-Davidson FLHRSE5 CVO Road King 5
• 2005-2017 Harley-Davidson FLHT Electra Glide
• 2005-2017 Harley-Davidson FLHT Electra Glide Standard
• 2005-2017 Harley-Davidson FLHTC Electra Glide Classic
• 2005-2017 Harley-Davidson FLHTC103 Electra Glide Classic
• 2005-2017 Harley-Davidson FLHTCU Electra Glide Ultra Classic
• 2005-2017 Harley-Davidson FLHTCU103 Electra Glide Ultra Classic
• 2005-2017 Harley-Davidson FLHTCUI Electra Glide Ultra Classic
• 2005-2017 Harley-Davidson FLHTCUL Ultra Classic Low
• 2005-2017 Harley-Davidson FLHTCUSE CVO Electra Glide Ultra Classic
• 2005-2017 Harley-Davidson FLHTCUTG Tri Glide Ultra Classic
• 2005-2017 Harley-Davidson FLHTK Electra Glide Ultra Limited
• 2005-2017 Harley-Davidson FLHTKL Ultra Limited Low
• 2005-2017 Harley-Davidson FLHTKSE CVO Limited
• 2005-2017 Harley-Davidson FLHX Street Glide
• 2005-2017 Harley-Davidson FLHX103 Street Glide
• 2005-2017 Harley-Davidson FLHXS Street Glide Special
• 2005-2017 Harley-Davidson FLHXSE CVO Street Glide
• 2005-2017 Harley-Davidson FLHXXX Street Glide Trike
• 2005-2017 Harley-Davidson FLRT Freewheeler
• 2005-2017 Harley-Davidson FLS103 Softail Slim
• 2005-2017 Harley-Davidson FLST Heritage Softail
• 2005-2017 Harley-Davidson FLSTC Heritage Softail Classic
• 2005-2017 Harley-Davidson FLSTC103 Heritage Softail Classic
• 2005-2017 Harley-Davidson FLSTC103 Heritage Softail Classic Shrine
• 2005-2017 Harley-Davidson FLSTF Fat Boy
• 2005-2017 Harley-Davidson FLSTF103 Fat Boy
• 2005-2017 Harley-Davidson FLSTFB Fat Boy Lo
• 2005-2017 Harley-Davidson FLSTFB103 Fat Boy Lo
• 2005-2017 Harley-Davidson FLSTN Heritage Softail Deluxe
• 2005-2017 Harley-Davidson FLSTN103 Heritage Softail Deluxe
• 2005-2017 Harley-Davidson FLSTNSE CVO Heritage Softail Deluxe
• 2005-2017 Harley-Davidson FLSTSB Cross Bones
• 2005-2017 Harley-Davidson FLSTSC Heritage Softail Springer Classic
• 2005-2017 Harley-Davidson FLSTSE CVO Softail Convertible
• 2005-2017 Harley-Davidson FLTR Road Glide
• 2005-2017 Harley-Davidson FLTRI Road Glide
• 2005-2017 Harley-Davidson FLTRU Road Glide Ultra
• 2005-2017 Harley-Davidson FLTRUSE CVO Road Glide Ultra
• 2005-2017 Harley-Davidson FLTRX Road Glide Custom
• 2005-2017 Harley-Davidson FLTRSE3 CVO Road Glide 3
• 2005-2017 Harley-Davidson FLTRX103 Road Glide Custom
• 2005-2017 Harley-Davidson FLTRXS Road Glide Special
• 2005-2017 Harley-Davidson FLTRXSE CVO Road Glide Custom
• 2005-2017 Harley-Davidson FLTRXSE2 CVO Road Glide Custom 2
• 2005-2017 Harley-Davidson FXCW Rocker
• 2005-2017 Harley-Davidson FXCWC Rocker C
• 2005-2017 Harley-Davidson FXD Dyna Super Glide
• 2005-2017 Harley-Davidson FXDB Dyna Street Bob
• 2005-2017 Harley-Davidson FXDB103 Dyna Street Bob
• 2005-2017 Harley-Davidson FXDBI Dyna Street Bob
• 2005-2017 Harley-Davidson FXDC Dyna Super Glide Custom
• 2005-2017 Harley-Davidson FXDCI Dyna Super Glide Custom
• 2005-2017 Harley-Davidson FXDC103 Dyna Super Glide Custom
• 2005-2017 Harley-Davidson FXDF Dyna Fat Bob
• 2005-2017 Harley-Davidson FXDF103 Dyna Fat Bob
• 2005-2017 Harley-Davidson FXDFSE CVO Fat Bob
• 2005-2017 Harley-Davidson FXDFSE2 CVO Fat Bob 2
• 2005-2017 Harley-Davidson FXDI Dyna Super Glide Custom
• 2005-2017 Harley-Davidson FXDL Dyna Low Rider
• 2005-2017 Harley-Davidson FXDL103 Dyna Low Rider
• 2005-2017 Harley-Davidson FXDLI Dyna Low Rider
• 2005-2017 Harley-Davidson FXDWG Dyna Wide Glide
• 2005-2017 Harley-Davidson FXDWG103 Dyna Wide Glide
• 2005-2017 Harley-Davidson FXDWGI Dyna Wide Glide
• 2005-2017 Harley-Davidson FXDX Dyna Super Glide Sport
• 2005-2017 Harley-Davidson FXS Blackline
• 2005-2017 Harley-Davidson FXS103 Blackline
• 2005-2017 Harley-Davidson FXSB103 Breakout
• 2005-2017 Harley-Davidson FXSBSE CVO Breakout
• 2005-2017 Harley-Davidson FXST Softail Standard
• 2005-2017 Harley-Davidson FXSTB Night Train
• 2005-2017 Harley-Davidson FXSTC Softail Custom
• 2005-2017 Harley-Davidson FXSTD Softail Deuce
• 2005-2017 Harley-Davidson FXSTS Softail Springer
• 2005-2017 Harley-Davidson FXSTSSE CVO Softail Springer
• 2005-2017 Harley-Davidson FLSS103 Softail Slim S
• 2005-2017 Harley-Davidson FLSTFBS103 Fat Boy S
• 2005-2017 Harley-Davidson FLHTCSE CVO Electra Glide
• 2005-2017 Harley-Davidson FXDLS103 Dyna Low Rider S

Brand: Vance & Hines
Part Number: 35-4520
